Tekniset tiedot

Classification: Radio channel security sounder

Type of siren: Wireless

Installation method: Indoors

Compatibility: Operates with all Ajax hubs, and range extenders

Type of notification: Sound, Connector for external LED Available

Sound volume level: Adjustable, 81?105 dB at a distance of 1 m

Alarm length: Adjustable, 3?180 s

Indication of armed/disarmed status: Yes

Alarm signal delivery time: 0.15 s

Power supply: Battery: Two CR123A batteries, 3 V

Battery life: Up to 5 years

Jeweller radio technology: Communication range with central unit — up to 2,000 m in an open space. Two-way communication between devices. Operating frequencies — 868.0 - 868.6 MHz. Self-adjusting RF output power — up to 25 mW. Block encryption based on AES algorithm. Device polling period — 12?300 s.

Temperature sensor Available

Operating temperature range From -10°? to +40°?

Permissible humidity Up to 75%

Protection class of body IP50

Anti-sabotage

Protection against fraud

Jamming detection

Tamper-resistant

Remote setting and testing

Dimensions: 75 × 76 × 27 mm

Weight: 97 g

Warranty: Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty

Service life: 10 years

Compliance with the security alarm standards

EN 50131-1:2006 / A1:2009 / A2:2017

EN 50131-4:2019

EN 50131-5-3:2017

PD 6662:2017 (in terms of requirements for security system devices)

BS EN 50131

Security Grade (SG) 2

Radio Equipment Directive (RED)

ETSI EN 300 220-1 V3.1.1

ETSI EN 300 220-2 V3.2.1

Restriction of Hazardous Substances Directive (RoHS)

Electromagnetic Compatibility Directive (EMC)

ETSI EN 301 489-1 V2.2.3

ETSI EN 301 489-3 V2.1.1

Low Voltage Directive (LVD)

EN 62368-1:2014/A11:2017

EN 50385:2002/EN 62479:2010

Environmental class according to EN 50131 II

Complete set

HomeSiren siren

SmartBracket mounting panel

Connector for LED indicator

Two CR123A batteries (pre-installed)

Installation set

User's guide
